Technical data:
Gross vehicle weight: 3,500 kg
Permissible axle load 2x 1,800 kg
drawbar load: 100 kg
Unladen weight: approx. 700 kg
Loading height: approx. 490 mm
Chassis:
Two maintenance-free rubber spring axles. The entire
chassis is manufactured as a welded construction in lightweight steel
hot-dip galvanised. Towing device with V drawbar
and overrun hitch.
Tyres:
4-way, on a 5-hole steel rim, branded 185 R14 C
Drop sides:
Made of 30 mm steel profiles welded to the frame.
Front and rear walls can be folded down with galvanised fasteners.
Floor:
The floor is made of 18 mm screen-printed boards with countersunk
screws. Joints sealed.
Lighting:
Complete electrical installation according to StVZO 12V
Tail lights and licence plate lights, rear fog light
13-pin plug
Paint finish:
without / as completely hot-dip galvanised
Accessories:
- Hot-dip galvanised mudguards with mud flaps
- Reinforced folding support wheel
- 2x rear support
Technical approval:
- TÜV approval with expert opinion
